Cities are an interesting way to think about Software. Cities have foundations, like infrastructure for cars, electricity. Housing for people to live and work. Stores to sell and buy goods. Also, Cities are often referred to as an organism. Just like a large organization, a department, or a team are an organism. But these organisms are building software.

I first came across this idea in Mikio Braun’s post on Everyone Is Still Terrible At Creating Software:

Cities can be thought as platforms for human activities. They provide basic infrastructure like roads, electricity, buildings, shop space you can rent, and now Internet. Some of these pieces of infrastructure change very slowly (like roads), while others are much more flexible, like the way apartments or shops are used.

He compares how organizations are not capable of building software that looks and works like a city. Instead, if cities would look like the software companies build, they would be pretty useless and dangerous to live in.

When we use a city as an analogy for an organization, the different areas or blocks represent the parts of the organization. In e-commerce, there is one block with a large bank for the checkout, a mall for the catalog and search, and so on. The streets between the blocks depict the data that flows between the different parts. Some streets are big, others small. There might even be streets within a block, but by design small ones.

The design of the streets dictate the effectiveness of the city Link to heading

A too small street between two important blocks limits the interaction between the blocks and has crippling effects on other blocks. If the trucks and cars cannot use the street between two blocks, they might have to make detours to get to their destination. If the street does not even exist, it needs to be built, possibly replacing other infrastructure or even blocks.

Some trucks might have been designed in another country and are not even allowed to use the streets built in your city. Are you making sure the 40t truck can cross that bridge?

How streets look like in Software Link to heading

Just as the streets of a city define it’s shape for decades, the design of the data flow in an organization defines it’s shape for a considerable amount of time. This part of the architecture must have a careful design and not manifest itself by accident and happenstance. The result of this design will outlast a number of organizational changes in the future. And even enable them, or make them hard.

In software (-architecture for that matter) there are two different types of streets that people build: APIs and Event Streams. APIs are a simple way for system A to provide a service for other systems to consume or leverage. For example, a system that exposes if an article is in stock, or the current price of that article.

In an Event Streaming environment, system A would publish an event describing the fact that the article is in stock. Another system would publish an event containing the price. A third system responsible for showing a catalog or offering search capabilities, e.g., would then need to merge these streams in order to have the final data in shape for the use-case.

API-First Link to heading

I believe the core idea of API-first was originally invented by Jeff Bezos’ API mandate:

1. All teams will henceforth expose their data and functionality through service interfaces.
2. Teams must communicate with each other through these interfaces.
3. There will be no other form of interprocess communication allowed: no direct linking, no direct reads of another team’s data store, no shared-memory model, no back-doors whatsoever. The only communication allowed is via service interface calls over the network.
4. It doesn’t matter what technology they use. HTTP, Corba, Pubsub, custom protocols — doesn’t matter.
5. All service interfaces, without exception, must be designed from the ground up to be externalizable. That is to say, the team must plan and design to be able to expose the interface to developers in the outside world. No exceptions.
6. Anyone who doesn’t do this will be fired.
7. Thank you; have a nice day!¹

The interesting bit in this is that API First is an interpretation of the memo. He actually mentions pubsub as a means to communicate. Yet, the majority of people first think about APIs.

What happens over time is as we move on, build new features, change strategies and course, we keep adding more APIs. We add more calls to the system in order to get the data we need for the new feature to work.

Eventually we end up with a call graph so complex that hardly any single engineer can still understand how all of this actually works. Suddenly, this one request the user issued, is calling 10, 20, 30 different APIs. How do you debug latency issues? Evolving the different SLOs over time is a challenge – they all depend on one another. And how do you remove this one API in the middle?

Debugging latency is simple: we add distributed tracing. Another vendor, additional technology that provides us a filtered view on what is going on, because the amount of tracing data would explode any cloud storage. Those systems are not really cheap as well. And you need all teams to implement it.

Teams negotiate their SLOs and their rate limits. Maybe we reach a stable state and everything works. But then the next change is around the corner. SLOs and rate limits don’t match anymore. Your local project now depends on other teams with potential crippling effects.

And with changes we have to adapt the APIs and their schema. Over time, different clients start using the API with different needs. Evolving the schema becomes non-trivial. For one use case a field might be optional, but for another it is required. The complexity for the API provider increases with every new feature. Maintenance and improvements are getting more difficult. And for use case A the latency profile might be a match, but use case B requires the response in a tenth of the latency. The technology choices might not match anymore, only a different storage system for the two use cases can match the competing requirements.

Events first Link to heading

An alternative to this is to design the streets as a stream of events. These events describe the data when it was created, updated, or deleted. And they follow a centrally available schema model. Clients that require the data need the schema which they can simply pull from the “schema registry”.

Clever schema implementations can even allow for decentralized schema changes as long as they are compatible. Depending on how careful you design and evolve your schemata, you can even change data producers and consumers independently of one another. Only if the data consumer actually needs the new data, they need to update their code base with the new schema design.

The underlying mechanism that enables all of this are log-based event streaming systems. They are based on a simple insight: we need to distribute data the same way as databases do this when they replicate. We do not want to share the Database between multiple services and only one system can write to the database. But we can scale the reads by adding “read replicas”. Systems can join the different streams to map the data into an optimized version for their use case.

Log-based event streaming systems have two different modes of operation. They can act as a simple message queue, a never ending stream of events. But they also act as a table of data. Kafka for example can compact a stream and remove duplicate messages for the same key, only retaining the last value that was published.

With this you can add, remove, or adapt data consumers at any point in time, without even talking to the data producer. There is only one point where the consumer maps producer’s schema to the schema used internally. The consumer is responsible for their schema and not the producer.

The city block responsible for the customer domain model publishes details about the customers. The city block responsible for order fulfillment is only interested in a subset of the data and can map the data before it enters their city block.

What now? Link to heading

Over time, we have created these literate big balls of mud, an illusion of a microservice architecture, that promised autonomy. Instead, we got endless alignment. We need to untangle this if we want to enable change. The more we bake our assumptions into code and relationships between APIs, the harder change becomes.

The gist of this is: focus on designing the streets. The way data flows through an organization and its systems is the bottleneck in regard to change. The more complex this flow is, the more difficult change becomes. And change is inevitable.

This is also a great point to add a Russel Ackoff (of course!) quote:

Performance of a system depends on how the parts interact, not on how they act taken separately.

Additional Resources Link to heading

There is a nice interview with Scott Havens on the Idealcast: Simplifying The Inventory Management Systems at the World’s Largest Retailer Using Functional Programming Principles. In this episode Havens describes their journey from migrating a convoluted and nested set of APIs to a system built on event streaming foundations. This is a great resource to start understanding this better. And Gene Kim is a great proponent of adaptability.

Martin Kleppmann pioneered this in 2014(!) in his talk “Turning the database inside out with Apache Samza”. One of my all-time favorites!
